CadnaR is the powerful software tool for the calculation and assessment of sound inside rooms and at workplaces. With its various features and software configurations, CadnaR covers the widest range...

Key Product Features

Model: CadnaR

VDI3760, Diffuse Field & Hybrid Calculation

Digital, Server or Cloud Licence Key

Presentation and Reports

Third-Party Software Import

Fast Calculation Process

Simple Export Formats

Aural Presentation

Dynamic 3D Display

CadnaR Software Options

CadnaR is a clearly arranged software enabling the user to easily build models and make precise predictions. When the project becomes more complex you will benefit from the sophisticated input possibilities.

CadnaR offers flexible licensing options, either on-premises (via local or server USB dongle) or through cloud licensing.
Optional software updates and hotline support are available.
Available for one-time purchase or subscription.

find out more

Option CAL: Calculation and Handling

Option CAL increases the performance of CadnaR enormously by adding additional calculation methods and further features.

Additional calculation methods: VDI3760, diffuse field method, hybrid method (image sources + particles).
Further source types: line source, area
Calculation and visualisation of the voxel grid.
Usage of the receiver chains.
Plot Designer for printing customised layouts.
Automatic calibration of absorption and scattering coefficients to achieve user-defined target reverberation times.
Dosimeter function.
Batch calculation.

find out more

Option VIS: Visualisation

Option VIS adds visualisation features to get a deeper understanding of the results and for presentation purposes.

Visualisation of the calculation: calculation rays in 3D, particle animation.
Import of textured 3D-Objects for presentation purposes.
Usage of high-resolution bitmaps (e.g. as a layout plan).
Vertical grid and 3D grid.

find out more

Option ORG: Project Organisation

With Option ORG, the organisation and handling of projects of any size is massively improved.

Grouping of objects (Objectree).
Usage of variants.
Efficient handling and comparison of up to 16 scenarios in a single file.
Calculation of partial levels.
CUDA calculation.
Import of DWG and DXF files.

Option AUDIO

Option AUDIO is a must have extension for acoustics experts who need to calculate reverberation times, Speech Transmission Index (STI) and further parameters on top of the sound pressure levels.

Calculation and auralisation of room acoustic and psychoacoustic parameters.
Calculation of energetic impulse responses and echograms.
Calculation of reverberation time (T10, T20, T30).
Calculation of the Speech Transmission Index (STI, STIPA).
Calculation of further parameters like e.g. Alcons, C60, D50, CIS and EDT.

Option OFFICE

Option OFFICE includes a selection of features from both options CAL and ORG for the handling, evaluation and optimisation of offices and open plan offices. Usually to be combined with Option T (or Option AUDIO).

Calculation and evaluation of receiver chains.
Horizontal grid calculation (2D).
Import of DWG files.
Export of full reports in MS Excel and MS Word.
Grouping of objects (Objectree).
Plot Designer for printing customised layouts.

Option T

Option T adds on selected features of Option AUDIO for the calculation and representation of the reverberation time (T20, T30). CadnaR with Options OFFICE and T represents the cost-efficient solution for office and also industrial applications with limited size and complexity when visualisations are not necessary.

Calculation of energetic impulse responses and echograms at receivers.
Calculation of reverberation time (T20, T30).
Grid calculation for T20 and T30.

CadnaR.Scan App - Room Capture with LiDAR & iPhone

With CadnaR.scan, you can quickly create a digital room model of your surroundings. Quickly create simplified 3D scans of rooms and entire floors, including walls, built-in wall elements, and objects in the room. The model can then be imported into CadnaR for further acoustical processing.

Industrial Acoustics

Industry acoustics comprise a wide range of applications which are succesfully managed by CadnaR. From the simple determination of the noise impact at work spaces to the full assessment and improvement of a industrial hall, CadnaR has been especially designed for the particular requirements of any project. CadnaR includes the following industry-specific features:

Overview of CadnaR for industry acoustics

Precision Room Modelling at Your Fingertips

CadnaR provides powerful tools to efficiently manage any scenario, guiding you through the setup of your acoustic model and the assignment of appropriate absorption, scattering, and transmission properties. Whether optimizing an open-space office for a productive work environment or ensuring excellent speech intelligibility in a lecture hall, CadnaR enables you to assess acoustic quality using industry standards and advanced evaluation methods.

Overview of CadnaR for industry acoustics

Precision Room Modelling at Your Fingertips

Key Product Specifications

User Friendly, Logical Software

Vertical Grid and 3D Grid

Frequency Spectra

Particle Maps

Reverberation, Absorption and Scattering Coefficients

Dosimeter Function

Objectree

Partial Levels

Import of DWG and DXF files

Speech Transmission Index

Calculation of Energetic Impulse Responses

Sound Transmission

Cadna Suite

The Cadna suite of software integrates seamlessly with CadnaB and CadnaR, extending its capabilities from environmental noise prediction to indoor acoustics and the detailed acoustic performance of building components.
